Compatible Years/Models: (1999 to Present) Harley-Davidson® Touring Models
Spring Rate Guide 1999-2008 Touring Models 115 Spring - Solo under 250lbs* 130 Spring - Standard 2-up riding 140 Spring - Heavy Duty over 500lbs *115 Spring is Powder Coated Gray.
Designed for the Harley-Davidson® touring enthusiast who expects the ultimate in ride performance. Most importantly, experience exceptional handling, unrivaled tunability, and ride performance. Nowaskey® 13 inch Remote Reservoir Rear Shocks are built for every riding style from the aggressive bagger to the long-distance rider. For example, the on-the-fly tuning instantly adjusts for your riding style, road conditions, and varying payload. Set the sag with the adjustable preload, then fine-tune the response with adjustable compression and rebound damping. Reservoir mounts are not included.
THE NOWASKEY DIFFERENCE Our 13 inch touring remote reservoir suspensions are designed and built to exacting specifications. All of our products are hand-assembled in the USA with American-made materials. Each shock is individually dyno-tuned and mated to its twin for consistent and exceptional performance.
FEATURES
Remote reservoir cylinder offers an independent 6-position compression adjustment with a larger nitrogen volume.
Steel-braided Teflon® lines utilizing O-ring connection points for 360° of rotation.
Proprietary tuned primary piston and valving to allow a more aggressive riding style.
Proprietary tuned compression adjuster for a broader range of adjustment on the reservoir.
1" Teflon® lined wide misalignment spherical joints to compensate for misalignment on OEM frame mounts.
Rebound adjustable eyelet O-ring sealed with 80 clicks for ultra-fine tuning.
Custom-designed lightweight spring hardware and the ability to adjust the preload by hand.
(4) spring rates available 115lbs/in, 130lbs/in, 140lbs/in, 150lbs/in (powder coated).
Maxima 3.0 WT Full Synthetic Fluid.
Preload setting on both shocks allows suspension adjustment based on rider, passenger, and gear weight for optimal performance.
Progressive rate springs stiffen quickly for improved handling when elevating to high-performance riding.
Exceptional shock length adjustment of +8/-2 mm.
High-pressure nitrogen gas-charged design resists shock fading with low-friction shaft/seal head design for smooth performance.
Remote reservoir rear shocks are fully serviceable and rebuildable.
This reservoir rear suspension system changed the ride and handeling of my 2022 Street Glide ST dramatically! Just holding them in my hand and looking at the finely tuned engineering and quality machining prior to the install was an eye opener! They are LIGHT and built like a Swiss watch! On my first test ride I could feel the difference before I got out of the parking lot! That day was full of hard riding in the beautiful Black Hills and I felt like I was on a completely different motorcylce. THEN, Pete fine tuned them after my ride and comments and I had a hole new appreciation for the fine tuning features! Pete really knows his stuff and this product proves it!!
B
B.R.
Above the rest
As a long distance rider suspension is key to laying down miles. Installed these on my RoadGlide and the amount of adjustability is great. From packing light or heavy or even riding two up you can truly dial it in to your riding comfort and style. After putting them on the bike I took off and hit the highway to test them out in less then 90 days! I put close to 20k on them and hit 27 states without any suspension issues. My wife wishes her mini van was as smooth as my bike pounding down the highway.
C
Customer
Game Changer
These shocks have changed my opinion on larger bikes. I rode King Nothing for a week which is Pete's personal bike and I am beyond impressed. The smooth ride, the cornering, the quality of the product, and the ability to make adjustments while on the road are just a few great things about these shocks. They are a must!
C
Caleb Witter
13" remote reservoir shocks
Best on the market, on the fly adjustments, great quality and great customer service
