Koso HD-03X / TFT Gauge Set for Harley-Davidson® 2014-2023
- Free shipping on this part
- Returns and exchanges: see our policy
- Questions? Call 715-235-3659 or chat with us on the site.
Description
Koso HD-03X / TFT Gauge Set for Harley-Davidson® 2014-2023
Upgrade your Harley-Davidson Bagger with the Koso HD-03X TFT Gauge Set, designed for 2014–2023 Street Glide, Road Glide, Electra Glide, and Ultra Limited models. This plug-and-play gauge set integrates seamlessly with your bike and features smartphone connectivity via the KOSO K Link app, giving you full control of your dashboard from your device.
Monitor real-time data including speed, fuel level, oil temperature, gear position, RPM, horsepower, tire pressure, and more. The GPS integration lets you locate your bike quickly, while diagnostics and system health monitoring help maintain peak performance. Customize the look with analog or digital display modes and 7 backlight colors, giving 14 unique display combinations.
Whether you want ultimate control, real-time diagnostics, or a stylish upgrade, the Koso HD-03X is the ultimate gauge solution for Harley-Davidson Baggers.
Features
- Plug-and-play TFT gauge set
- Smartphone integration via KOSO K Link app
- Monitor: speed, fuel level, oil temp, gear, RPM, horsepower, tire pressure
- GPS tracking to locate your bike
- Analog & digital interface options
- 7 backlight colors, 14 display combinations
- Real-time diagnostics and system health monitoring
- Tachometer: 0–8,000 RPM
- RPM shift light: 1,000–8,000 RPM
- Speedometer: 0–199 MPH (0–299 km/h)
- Odometer: 0–999,999 miles/km
- Tripmeter A/B, average fuel consumption, remaining mileage
- Oil temperature meter & max oil temperature record
- Clock: 12/24-hour format
- Volt meter: DC 8–18 V
- Horsepower meter: 8.8–200 HP
- G-Force meter: 0–2 G
- Tire pressure monitor
- Altitude: 0–10,000 m / 0–32,800 ft
- Indicator lights: turn signals, high beam, oil pressure, traction control, cruise, ABS, check engine, rain mode, fuel level, and more
- Gear indicator: OFF, N, P, R, 1–6
- Effective temp range: -4–140 °F (-20–60 °C)
- Voltage: DC 12 V
- Compass & multiple unit displays
- Auto day/night mode display
Fitment
- Fits most 2014–2023 Harley-Davidson Baggers
- Compatible with: Street Glide, Road Glide, Electra Glide, Ultra Limited
- Direct replacement, plug-and-play installation
Fitment
Fits Harley-Davidson Touring Models (Road Glide, Street Glide, Electra Glide, Ultra Limited) - 2014 to 2023
Not sure it fits your bike? Call 715-235-3659 or chat with us on the site and a tech can confirm it with you.
Specifications & Installation
| Brand | Original Garage Moto |
|---|---|
| Part number | 105886 |
| Product type | Gauges |
| Monitor | speed, fuel level, oil temp, gear, RPM, horsepower, tire pressure |
| Tachometer | 0–8,000 RPM |
| RPM shift light | 1,000–8,000 RPM |
| Speedometer | 0–199 MPH (0–299 km/h) |
| Odometer | 0–999,999 miles/km |
| Clock | 12/24-hour format |
| Volt meter | DC 8–18 V |
| Horsepower meter | 8.8–200 HP |
| G-Force meter | 0–2 G |
| Altitude | 0–10,000 m / 0–32,800 ft |
| Indicator lights | turn signals, high beam, oil pressure, traction control, cruise, ABS, check engine, rain mode, fuel level, and more |
Videos
Want it installed right? Book the Nowaskey Speed Shop or call 715-235-3659.
Questions Riders Ask
Will this fit my bike?
Fits Harley-Davidson Touring Models (Road Glide, Street Glide, Electra Glide, Ultra Limited) - 2014 to 2023.
Save your bike with Shop by Bike and we check it for you. Not sure? Call or chat with us on the site and a tech can confirm it with you.
What's the part number?
Manufacturer part number BA064930. Our item number is 105886.
Can I install it myself?
Most riders with basic tools and a service manual can. The Specifications & Installation tab lists difficulty, time and guides where we have them. Prefer a pro install? Book a Speed Shop slot and call to check current availability.
Who do I talk to after I buy?
Our techs. Call 715-235-3659 or chat with us on the site and you will reach the people who know these parts.
Still have a question? Call 715-235-3659 or chat with us on the site.
